Market Roles in the German Energy Market
The German energy market is characterized by a clear separation of grid operation and supply (unbundling). The various market roles are organized across four layers and communicate via standardized processes (GPKE, MaBiS, WiM) and data formats (EDIFACT). This guide provides a complete overview.
- The German energy market separates grid operation from supply through unbundling -- ensuring non-discriminatory access for all participants.
- 15+ distinct market roles operate across four layers: Grid, Market, Metering and Customer.
- Standardized communication processes (GPKE, MaBiS, WiM) and EDIFACT data formats enable seamless interaction.
- Key regulations include EnWG, MsbG, StromNZV, and BNetzA rulings (BK6/BK7).
- Smart meter rollout, Redispatch 2.0 and prosumer integration are reshaping the market landscape.
- For Energy Providers, Utilities, Grid Operators and Metering Operators.
Energy Market Structure
The German energy market is defined by a clear separation of grid operation and supply (unbundling). The various market roles are organized into four layers and communicate via standardized processes (GPKE, MaBiS, WiM) and data formats (EDIFACT). This structure ensures non-discriminatory grid access for all market participants and promotes competition in the energy market.
Liberalization and Unbundling
The liberalization of the German electricity market began in 1998 with the implementation of the first EU Internal Market Directive. The core principle: separation of monopoly areas (grid operation) from competitive areas (generation, trading, supply).
- 1998: First Energy Industry Act (EnWG) -- beginning of market liberalization
- 2005: Second EnWG -- establishment of the regulatory authority (BNetzA)
- 2011: Energy transition after Fukushima -- increased renewable energy feed-in
- 2016: Metering Operation Act (MsbG) -- Smart Meter Rollout
- 2021: Redispatch 2.0 -- integration of distributed generation plants
The Four Market Layers
- Grid Layer: Transmission System Operators (TSO/UNB), Distribution System Operators (DSO/VNB) and Connection Grid Operators (CGO/ANB) provide the physical infrastructure. They are regulated monopolies subject to tariff regulation by BNetzA.
- Market Layer: Suppliers (LF), Balance Responsible Parties (BRP/BKV), Direct Marketers (DV) and other actors organize energy trading. Competition prevails here -- every customer can freely choose their supplier.
- Metering Layer: Metering System Operators (MSO/MSB), Gateway Administrators (GWA) and Energy Service Providers (ESA) capture and process metering data. Since the MsbG, competition also exists here between default and competitive MSOs.
- Customer Layer: End consumers, plant operators and prosumers as end users and distributed generators. They are the economic drivers of the system and increasingly active market participants.
Unbundling Requirements
Unbundling (separation) is designed to prevent discrimination and enable competition:
- Legal Unbundling: Grid operation must be conducted in a separate legal entity (for operators serving more than 100,000 customers)
- Operational Unbundling: Independent decision-making authority for grid operations
- Informational Unbundling: Confidential treatment of commercially sensitive data
- Accounting Unbundling: Separate accounts for grid and supply activities (all companies)
For TSOs, even stricter requirements apply: ownership unbundling (OU) or Independent Transmission Operator (ITO) model.
Legal Foundations
Market roles and their obligations are defined by a complex regulatory framework:
- EnWG -- Energy Industry Act (Energiewirtschaftsgesetz): The fundamental law of the energy market governing grid access, unbundling and regulation
- MsbG -- Metering Operation Act (Messstellenbetriebsgesetz): Regulates the smart meter rollout and the rights/obligations of metering system operators
- StromNZV -- Electricity Grid Access Regulation (Stromnetzzugangsverordnung): Details on grid access, balancing group system and schedule management
- StromNEV -- Electricity Grid Fee Regulation (Stromnetzentgeltverordnung): Calculation of grid usage fees
- EEG -- Renewable Energy Sources Act (Erneuerbare-Energien-Gesetz): Promotion and feed-in of renewable energies
- KWKG -- Combined Heat and Power Act (Kraft-Warme-Kopplungsgesetz): Promotion of high-efficiency CHP plants
Additionally, BNetzA rulings (BK6/BK7) such as GPKE, MaBiS, WiM, MPES regulate technical and operational details.
Communication between Market Participants
Market communication is conducted exclusively via standardized formats and processes:
- EDIFACT: Electronic data format based on UN/EDIFACT -- standardized through edi@energy (BDEW/DVGW)
- AS4: Secure communication platform for data exchange (increasingly replacing email-based EDIFACT)
- Market Partner IDs: Unique identifiers (BDEW code number, EIC) for identifying all participants
- Deadlines: Fixed response times (e.g., 5 business days for supplier switch confirmation)
Grid Layer
The grid layer encompasses all actors responsible for the physical transport of electricity -- from the extra-high voltage grid down to the household connection.
Transmission System Operator (UNB)
Grid LayerOperates the extra-high voltage grid (220-380 kV) and is responsible for system stability, balancing energy and interregional electricity transport.
Core Tasks
- Operation and maintenance of the transmission grid
- System management and frequency control
- Procurement and deployment of balancing energy
- Congestion management and redispatch
- Balance coordination (BIKO role)
Relevant Processes
Communicates With
Examples
TenneT, 50Hertz, Amprion, TransnetBW
Distribution System Operator (VNB)
Grid LayerOperates the medium and low voltage grid and provides the connection between the transmission grid and end consumers.
Core Tasks
- Operation of the distribution grid
- Grid connection and grid access
- Meter data management
- Grid usage billing
- Master data maintenance for market locations
Relevant Processes
Communicates With
Examples
E.ON Netz, EnBW, municipal utilities, regional operators
Connection Grid Operator (ANB)
Grid LayerThe grid operator to whose network a market location is physically connected. Often identical to the DSO.
Core Tasks
- Provision of the grid connection
- Technical processing at the connection point
- Master data reporting for generation plants
- Coordination of redispatch measures
Relevant Processes
Communicates With
Examples
Identical to DSO or specialized companies
Market Layer
The market layer organizes the trading and balancing settlement of energy. Here, suppliers, balance responsible parties and direct marketers operate.
Supplier (Lieferant)
Market LayerSupplies end customers with electricity or gas and is contractually responsible for energy delivery.
Core Tasks
- Concluding supply contracts with end customers
- Energy procurement and portfolio management
- Balancing group assignment of customers
- Energy billing to end customers
- Switching processes and customer service
Relevant Processes
Communicates With
Examples
E.ON, Vattenfall, EnBW, municipal utilities
Balance Responsible Party (BKV)
Market LayerResponsible for maintaining a balanced position between feed-in and withdrawal within a balancing group.
Core Tasks
- Management of the balancing group
- Schedule submission to the TSO
- Forecasting and procurement
- Settlement of balancing group deviations
- Balancing energy settlement
Relevant Processes
Communicates With
Examples
Large utilities, energy traders, industrial companies
Balance Coordinator (Bilanzkreiskoordinator)
Market LayerRole of the TSO for coordination and settlement of all balancing groups within a control area.
Core Tasks
- Aggregation of all balancing group data
- Calculation of balancing energy
- Balancing group settlement
- Clearing between balancing groups
- Publication of balancing energy prices
Relevant Processes
Communicates With
Examples
TenneT (as BIKO), 50Hertz (as BIKO)
Direct Marketer (Direktvermarkter)
Market LayerMarkets electricity from renewable energy sources directly on the spot market on behalf of plant operators.
Core Tasks
- Direct marketing of renewable electricity
- Exchange trading and portfolio management
- Forecast generation for renewable plants
- Settlement with plant operators
- Remote control of generation plants
Relevant Processes
Communicates With
Examples
Next Kraftwerke, Statkraft, EnBW
Dispatch Responsible Party (Einsatzverantwortlicher)
Market LayerResponsible for the dispatch of a technical resource within the Redispatch 2.0 framework.
Core Tasks
- Control of generation plants
- Implementation of redispatch calls
- Data reporting to grid operators
- Balancing settlement of curtailed energy
Relevant Processes
Communicates With
Examples
Direct marketers, plant operators, aggregators
Metering Layer
The metering layer encompasses all actors responsible for capture, transmission and processing of metering data.
Default MSO (Grundzustandiger MSB)
Metering LayerThe automatically responsible metering system operator for a grid area, typically the local grid operator.
Core Tasks
- Installation of metering equipment
- Operation and maintenance of metering points
- Meter reading and data transmission
- Smart meter rollout
- Compliance with price caps
Relevant Processes
Communicates With
Examples
Grid operator subsidiaries, municipal utilities
Competitive MSO (Wettbewerblicher MSB)
Metering LayerIndependent provider for metering operations, freely selectable by the connection user.
Core Tasks
- Offering alternative metering solutions
- Enhanced visualization and analytics
- Integration with energy management systems
- Flexible tariff models
- Specialized solutions for commercial/industrial clients
Relevant Processes
Communicates With
Examples
EHA, Discovergy, Commetering
Energy Service Provider (Energieserviceanbieter)
Metering LayerOffers energy-related services based on metering data.
Core Tasks
- Analysis and visualization of energy data
- Energy consulting and optimization
- Demand response services
- Smart home integration
- Billing services
Relevant Processes
Communicates With
Examples
Energy consultants, smart home providers, billing service providers
Gateway Administrator (Gateway-Administrator)
Metering LayerAdministers Smart Meter Gateways and controls secure data communication.
Core Tasks
- Configuration of Smart Meter Gateways
- Certificate management (SM-PKI)
- Control of data transmission
- Security management
- Remote maintenance and updates
Relevant Processes
Communicates With
Examples
MSO internal function, specialized IT service providers
Customer Layer
The customer layer encompasses the end users of energy -- both pure consumers and distributed generators and prosumers.
End Consumer (Letztverbraucher)
Customer LayerThe final recipient of energy for own consumption.
Core Tasks
- Concluding supply contracts
- Paying energy bills
- Choosing supplier and MSO
- Providing meter readings
- Tolerating smart meter rollout
Relevant Processes
Communicates With
Examples
Households, commercial enterprises, industrial users
Plant Operator (Anlagenbetreiber)
Customer LayerOperator of a power generation plant (e.g., PV, wind, CHP).
Core Tasks
- Operation of the generation plant
- Registration in the Market Master Data Register (MaStR)
- Selection of the marketing model
- Compliance with technical requirements
- Tolerating redispatch measures
Relevant Processes
Communicates With
Examples
PV operators, wind farm operators, CHP operators
Prosumer
Customer LayerCombination of producer and consumer -- generates and consumes energy.
Core Tasks
- Optimizing self-consumption
- Surplus feed-in
- Storage management
- Participation in flexibility markets
- Integration of controllable consumption devices
Relevant Processes
Communicates With
Examples
Homeowners with PV, commercial buildings with CHP
Market Communication Processes
Market communication in the German energy market is fully standardized. The Bundesnetzagentur (BNetzA) has established binding process descriptions through its ruling chambers (BK6 for electricity, BK7 for gas) that all market participants must follow. These processes define exact workflows, deadlines and message formats.
Core Principles of Market Communication
- Full Automation: All processes run electronically via EDIFACT messages -- no manual steps
- Deadline-bound: Every process step has defined response deadlines (e.g., 5 business days, 10 business days)
- Bilateral Communication: Direct message exchange between the involved parties
- Clearing Houses: Dispute resolution mechanisms exist (e.g., BDEW Clearing)
- Format Validation: Syntactic and semantic validation of all messages before processing
Business Processes for Electricity Supply to Customers
Governs all processes related to end customers: supplier switching, move-in/move-out, grid usage billing and master data exchange.
- Supplier Switch: Registration by new supplier > confirmation/rejection by DSO (5 BD) > deregistration to old supplier
- Move-in: Customer reports move-in to supplier > supplier registers with DSO
- Move-out: Customer terminates or supplier reports move-out
- Notice Period: Min. 3 weeks before supply start
Messages: UTILMD (master data), MSCONS (meter readings), INVOIC (invoices)
Market Rules for Balancing Group Settlement
Defines data exchange for balancing group management and settlement between all relevant parties.
- Aggregate Time Series: DSO reports aggregated values per balancing group
- Balancing Group Summary: BIKO creates total balance per balancing group
- Balancing Energy: Calculation of deviations between schedule and actual
- Monthly Settlement: Balancing energy costs to BRP
Messages: MSCONS (time series), UTILTS (schedules), INVOIC (settlement)
Switching Processes in Metering
Governs all processes related to metering operations: MSO switching, device replacement, meter data transmission.
- MSO Switch: Connection user commissions wMSB > request to gMSB > meter exchange
- Device Replacement: Meter removal/installation with protocol and data transmission
- Meter Data Transmission: MSO delivers readings to authorized recipients (DSO, Supplier)
- Deadlines: MSO switch requires min. 2 months lead time
Messages: UTILMD (device master data), MSCONS (meter readings), ORDERS/ORDRSP
Market Processes for Generation Plants
Standardizes communication for distributed generation plants (EEG, CHP, others).
- Plant Master Data: Reporting of technical data to DSO/CGO
- Marketing Switch: Change between feed-in tariff and direct marketing
- Assignment: Assignment of plant to balancing group/direct marketer
- Compensation: Processes for curtailed energy and compensation
Messages: UTILMD (plant data), MSCONS (feed-in values), INVOIC (EEG remuneration)
Business Processes for Gas Supplier Switching
Equivalent to GPKE for the gas market with gas-specific adaptations.
- SLP Customers: Standard load profile customers with estimated consumption
- RLM Customers: Interval metering for large consumers
- Calorific Value Transmission: Additional gas-specific measurement parameters
- Allocation: Assignment of gas volumes to balancing groups
Messages: UTILMD, MSCONS, INVOIC (analogous to GPKE)
Congestion Management with Renewables/CHP
Since 01 October 2021: All generation plants above 100 kW (and controllable consumption devices) are included in congestion management.
- Master Data Exchange: Technical resources are reported in detail (capacity, location, controllability)
- Planned Values: EIV reports daily planned values for generation/consumption
- Dispatch Call: Grid operator can request curtailment/increase
- Balancing Compensation: BRP settles deviations
- Compensation: Plant operator receives compensation for curtailment
Messages: UTILMD (master data TR/SR/LR), UTILTS (planned values), special dispatch formats
Example: Supplier Switching Process
A typical supplier switch under GPKE follows this procedure:
- Day 0: Customer signs contract with new supplier (LF-new). Customer authorizes LF-new to handle termination and registration.
- Day 1: LF-new sends termination notice to LF-old (optional, if authorized by customer)
- Day 1: LF-new sends registration (UTILMD) to DSO with desired supply start date
- Day 1-5: DSO validates registration (MaLo exists? Data correct? No duplicate switch?)
- Day 6: DSO confirms registration (UTILMD response) or rejects with reason
- Day 6: DSO sends deregistration to LF-old
- Day 6-10: LF-old confirms deregistration or objects
- Supply Start: From agreed date, LF-new supplies; DSO assigns MaLo to LF-new's balancing group
- After Switch: MSO transmits meter reading at switch date for final invoice
Minimum Lead Time: Supplier switch must be registered at least 3 weeks before desired supply start. Only one switch per calendar month is permitted per market location.
EDIFACT Message Types
Market communication uses standardized EDIFACT formats according to edi@energy for data exchange between market participants. EDIFACT (Electronic Data Interchange for Administration, Commerce and Transport) is an international UN standard, specified for the German energy industry by BDEW and DVGW.
Structure of an EDIFACT Message
Every EDIFACT message follows a standardized structure:
- UNA: Service String Advice -- defines delimiters
- UNB: Interchange Header -- sender, recipient, timestamp
- UNH: Message Header -- message type and version
- Segments: Content data according to Message Implementation Guide (MIG)
- UNT: Message Trailer -- segment count
- UNZ: Interchange Trailer -- message count
The exact structure is defined in the MIGs (Message Implementation Guides), which edi@energy updates regularly.
Core Message Formats
Master Data -- customers, contracts, meters, plants. Used for registrations/deregistrations, device changes, master data updates
Meter Data -- meter readings, energy volumes, load profiles. The backbone of meter data transmission
Time Series -- schedules, forecasts, calculated values. Important for balancing and redispatch
Orders -- requests for device replacement, reading, disconnection/reconnection
Order Response -- confirmation or rejection of ORDERS requests
Invoices -- grid usage, metering, EEG surcharge, balancing group settlement
Payment Advice -- information about completed or planned payments
Fault Report -- technical faults at metering equipment
Acknowledgement -- syntactic validation and receipt confirmation
Application Error -- semantic error messages and rejections
Quote Request -- price enquiries for grid connections
Quote -- cost proposal for grid connection or extension
Versioning and Updates
EDIFACT formats are updated regularly:
- edi@energy: Joint platform of BDEW and DVGW for format maintenance
- Format Versions: Currently e.g. UTILMD 5.2g, MSCONS 2.4b
- Effective Dates: New format versions are introduced on fixed dates (01 April / 01 October)
- Transition Phase: Old and new versions are accepted in parallel during transitions
- Validation Tools: edi@energy provides free validation tools
Central Identifiers
The German energy market uses numerous standardized identifiers to uniquely identify locations, devices and market partners. These IDs are the foundation of automated market communication.
Location Identifiers
Since the introduction of the market/metering location model in 2017, consumption and feed-in points are identified through two separate ID systems:
11-digit numeric ID for each commercial withdrawal/feed-in point. The MaLo is the balancing point and is assigned to a balancing group. Issued by the DSO.
33-digit alphanumeric ID for technical metering points. Starts with country code (DE). One MaLo can have multiple MeLos (e.g., bidirectional metering). Issued by the DSO.
Unique ID for controllable generation plants in the context of Redispatch 2.0. Identifies the physical plant independently of the MaLo assignment.
Manufacturer-specific serial number of the meter or measuring device. For smart meters, also the gateway ID for communication.
Market Partner Identifiers
Each market participant requires unique identifiers for communication:
13-digit number for unique identification of market partners in EDIFACT communication. Issued by BDEW and mandatory for all market participants.
16-character European code for market participants, balancing areas and control zones. Relevant for cross-border trading and schedule management. Issued by ENTSO-E.
13-digit GS1 number for international location identification. Used in parallel with the BDEW code number in some cases.
Registration number in the BNetzA Market Master Data Register (Marktstammdatenregister). Mandatory for all generation plants and storage systems. Format: 3 letters + 12 digits.
Balancing Identifiers
- Balancing Group ID: 16-character identifier for balancing groups, format similar to EIC. Issued by BIKO/TSO.
- Control Zone ID: Identifier for the four German control zones (TenneT, 50Hertz, Amprion, TransnetBW)
- Grid Area ID: Unique identifier for each DSO's grid area
Further Reading
FAQ
The Distribution System Operator (DSO/VNB) operates the entire distribution grid in a given area. The Connection Grid Operator (CGO/ANB) is the specific grid operator to whose network a particular market location is physically connected.
- In most cases, the DSO and CGO are identical
- In grid areas with multiple operators, the CGO may differ
- The CGO is particularly relevant for Redispatch 2.0 and MPES
The Default Metering System Operator (gMSB) is responsible for the rollout of intelligent metering systems under MsbG.
- The gMSB is typically the local grid operator or its subsidiary
- Mandatory installation above certain consumption thresholds (> 6,000 kWh/year)
- End consumers can alternatively choose a Competitive MSO (wMSB)
- Price caps under MsbG must be observed
The GPKE (Geschaeftsprozesse zur Kundenbelieferung mit Elektrizitaet) is a BNetzA ruling that standardizes all processes between market participants.
- Supplier Switching: Complete workflow from contract change to supply start
- Move-in/Move-out: Registration and deregistration of consumers
- Master Data Exchange: Synchronization of customer data
- Meter Data Transmission: Standardized transfer of consumption data
A balancing group (Bilanzkreis) is a virtual account where electricity feed-in and withdrawal are balanced.
- Every market location must be assigned to a balancing group
- The BRP (BKV) is responsible for keeping it balanced
- Deviations are settled through balancing energy
- The settlement is handled by the BIKO (Balance Coordinator)
Redispatch 2.0 is the congestion management procedure in effect since October 2021, which for the first time includes renewable energy and CHP plants above 100 kW.
- Grid operators can instruct generation plants to reduce their feed-in
- Plant operators receive compensation for lost revenue
- New role of the Dispatch Responsible Party (EIV) for dispatch control
- Complex data exchange between CGO, EIV and BRP
The Market Location (MaLo) and Metering Location (MeLo) are different concepts in the German energy market.
- MaLo: Balancing point for energy volumes (commercial) -- identified by an 11-digit numeric ID
- MeLo: Physical measurement point (technical) -- identified by a 33-digit alphanumeric ID
- One MaLo can have multiple MeLos (e.g., bidirectional meter with separate feed-in/withdrawal)
- One MeLo can also be assigned to multiple MaLos (virtual division)
- Assignment and allocation are handled by the DSO
